EO-CQRS/eo-kafka - Kafka Producers and Consumers for Elegant Microservices

EO-CQRS is a set of components for creating elegant microservices we started to work on just a few weeks ago. The intent was to propose a clean and more maintainable alternative to Spring, Eventuate, Project Reactor, and others. Instead of calling static procedures, creating configuration classes, services, etc. we want to use clean and simple objects, the way they are supposed to be used. Today we will see how Kafka producers and consumers work in an elegant, object-oriented way.

Let’s say we want to create a Kafka Producer. This is how you would do it with the Spring Framework Kafka starter:

@Configuration
public class KafkaProducerConfig {

  @Bean
  public ProducerFactory<String, String> producerFactory() {
    final Map<String, Object> config = new HashMap<>();
    config.put(
      ProducerConfig.BOOTSTRAP_SERVERS_CONFIG,
      bootstrapAddress);
    config.put(
      ProducerConfig.KEY_SERIALIZER_CLASS_CONFIG,
      StringSerializer.class);
    config.put(
      ProducerConfig.VALUE_SERIALIZER_CLASS_CONFIG,
      StringSerializer.class);
    return new DefaultKafkaProducerFactory<>(config);
  }

  @Bean
  public KafkaTemplate<String, String> kafkaTemplate() {
    return new KafkaTemplate<>(this.producerFactory());
  }
}

@Autowired
private KafkaTemplate<String, String> kafkaTemplate;

  public void sendMessage(String msg) {
    kafkaTemplate.send(topicName, msg);
}

public void sendMessage(String message) {
  CompletableFuture<SendResult<String, String>> future = kafkaTemplate.send(topicName, message);
  future.whenComplete((result, ex) -> {
    if (ex == null) {
      System.out.println("Sent message=[" + message +
  "] with offset=[" + result.getRecordMetadata().offset() + "]");
    } else {
      System.out.println("Unable to send message=[" +
  message + "] due to : " + ex.getMessage());
    }
  });
}

This code is very imperative, also, very hard to test and reuse, thus it can lead to disaster in your software project.

This is how you can do it with eo-kafka:

With XML config file:

 final Producer<String, String> producer =
   new KfProducer<>(
     new KfXmlFlexible<String, String>("settings.xml")
       .producer()
   );

XML should be in resources dir, and has the following structure:

<producer>
  <bootstrapServers>cluster.svc:9092</bootstrapServers>
  <keySerializer>org.apache.kafka.common.serialization.StringSerializer</keySerializer>
  <valueSerializer>org.apache.kafka.common.serialization.StringSerializer</valueSerializer>
</producer>

Or with just passing the parameters which you need:

 final Producer<String, String> producer =
   new KfProducer<>(
     new KfFlexible<>(
       new KfProducerParams(
         new KfParams(
           new BootstrapServers("cluster.svc:9092"),
           new KeySerializer("org.apache.kafka.common.serialization.StringSerializer"),
           new ValueSerializer("org.apache.kafka.common.serialization.StringSerializer")
         )
       )
     )
   );

Here you can find the full mapping of Kafka properties, our classes for them, and XML tags for your files.

So far, so good, and now we can send message to the broker:

try (final Producer<String, String> producer = ...) {
      producer.send(
        "key2012",
        new KfData<>(
          "newRest28",
          "orders",
          1
        )
      );
    } catch (Exception e) {
        throw new IllegalStateException(e);
  }
}

Let’s see what we can do with Kafka Consumer:

Firstly, with Spring Kafka:

@Configuration
public class KafkaConsumerConfig {

  @Bean
  public ConsumerFactory<String, String> consumerFactory() {
    final Map<String, Object> props = new HashMap<>();
    props.put(
      ConsumerConfig.BOOTSTRAP_SERVERS_CONFIG,
      bootstrapAddress);
    props.put(
      ConsumerConfig.GROUP_ID_CONFIG,
      groupId);
    props.put(
      ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG,
      StringDeserializer.class);
    props.put(
      ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG,
      StringDeserializer.class);
    return new DefaultKafkaConsumerFactory<>(props);
  }

  @Bean
  public ConcurrentKafkaListenerContainerFactory<String, String>
  kafkaListenerContainerFactory() {
    final ConcurrentKafkaListenerContainerFactory<String, String> factory =
      new ConcurrentKafkaListenerContainerFactory<>();
    factory.setConsumerFactory(this.consumerFactory());
    return factory;
  }
}

@KafkaListener(topics = "topicName", groupId = "foo")
public void listenGroupFoo(String message) {
    System.out.println("Received Message in group foo: " + message);
}

And with eo-kafka:

Again, using XML File approach:

final Consumer<String, String> consumer =
  new KfConsumer<>(
    new KfXmlFlexible<String, String>("consumer.xml")
      .consumer()
  );

with following XML file structure:

<consumer>
  <bootstrapServers>cluster.svc:9092</bootstrapServers>
  <groupId>1</groupId>
  <keyDeserializer>org.apache.kafka.common.serialization.StringDeserializer</keyDeserializer>
  <valueDeserializer>org.apache.kafka.common.serialization.StringDeserializer</valueDeserializer>
</consumer>

Or with help of parameters:

final Consumer<String, String> consumer =
  new KfConsumer<>(
    new KfFlexible<>(
      new KfConsumerParams(
        new KfParams(
          new BootstrapServers("cluster.svc:9092"),
          new GroupId("1"),
          new KeyDeserializer("org.apache.kafka.common.serialization.StringDeserializer"),
          new ValueDeserializer("org.apache.kafka.common.serialization.StringDeserializer")
        )
      )
    )
  );

Now, we can consume some messages from the broker:

try (
  final Consumer<String, String> consumer =
      new KfConsumer<>(
        new KfFlexible<>(
          new KfConsumerParams(
            new KfParams(
              new BootstrapServers(this.severs),
              new GroupId("1"),
              new AutoOffsetReset("earliest"),
              new KeyDeserializer("org.apache.kafka.common.serialization.StringDeserializer"),
              new ValueDeserializer("org.apache.kafka.common.serialization.StringDeserializer")
            )
          )
        )
      )
  ) {
  // you need to be subscribed on a topic to iterate over data in the topic
      consumer.subscribe(new ListOf<>("orders-saga-init")));
      List<Dataized<String>> result = consumer.iterate("orders-saga-init", Duration.ofSeconds(5L));
    }
  }

By the way, you can create Kafka Consumer wrapping original KafkaConsumer:

KafkaConsumer origin = ...;
Consumer<String, String> producer = new KfConsumer<>(origin);

This solution is actually cleaner, more declarative, testable, and in the end: more maintainable. It perfectly decouples concepts, while the procedural one keeps them together.

As you see, object-oriented design helps to construct cleaner, simpler, more maintainable, cohesive, and less coupled software components. All these things are virtues for microservices’ architecture. By the way, in EO-CQRS we even introduced 4 principles of clean development process:

Simplicity is the virtue
No monolithic repositories
No manual deployments
Master branch is read-only

If you have some ideas how we can improve the microservices architecture, please submit the issue, and we will provide you feedback.
